| Motor | Yamaha PW-S2, 250/600 W, 75 Nm |
| Batería | 720Wh, 36v |
| Control Unit | Integrada en display |
| Display | Yamaha Display A2, LCD, Micro-USB |
| Cargador | Smart Charger, 4A |
| Cuadro | 29″, Aluminio 6061, Batería Extraible, Boost, 120mm |
| Horquilla | SR Suntour X1, aire, 120 mm, tapered |
| Amortiguador | SR Suntour Raidon R, aire, 210×47,5 mm |
| Cambio | Shimano Deore, RD-M5130, Shadow Plus, 10v |
| Mando Cambio | Shimano Deore, SL-M5130, Rapidfire Plus |
| Bielas | Raymon FC40, Aluminio forjado, ISIS |
| Plato | Raymon, Narrow Wide, 36T, CG |
| Cassette | Shimano CS-LG400, 11-43T |
| Cadena | Shimano CN-LG500 |
| Freno Delantero | Tektro Draco, 2 pistones, Disco Hidráulico |
| Disco Delantero | Tektro TR53, 203mm, 6 Tornillos |
| Freno Trasero | Tektro Draco, 2 pistones, Disco Hidráulico |
| Disco Trasero | Tektro TR53, 203mm, 6 Tornillos |
| Ruedas | Raymon VR23/DT210, 6 Tornillos, 15×110/12x148mm |
| Neumáticos | Schwalbe Nobby Nic Performance, Addix, 62-622, 29×2.40 |
| Puños | Raymon MTB, lock on |
| Manillar | Raymon Riser 31,8 mm, Sweep: 9 °, Rise: 20 mm |
| Ancho Manillar (mm) | 780 |
| Potencia | Raymon 31,8, Ahead |
| Dirección | FSA NO.69/62, Internal Cable Routing |
| Tija | Raymon, 34,9 mm |
| Longitud Tija (mm) | 350 |
| Cierre Tija | 38,9, Tornillo Allen |
| Sillín | Raymon |
| Caballete | KSA40, compatible |
| Peso (Kg) | 25,4 |
| Peso máx. admisible (kg) | 130 |
| Talla | Medida Cuadro (mm) | Reach (mm) | Stack (mm) |
| S | 400 | 415 | 624 |
| M | 420 | 440 | 633 |
| L | 440 | 465 | 643 |
| XL | 460 | 490 | 652 |
| TALLA | ESTATURA (cm) |
| S | 153 – 168 |
| M | 163 – 178 |
| L | 173 – 188 |
| XL | 183 – 198 |
